Factory direct sale high quality DY1000 hho brown gas generator
quartz glass tube sealing machine
DY1000 hho brown gas generator quartz glass tube sealing machine
Vacuum sealing equipment is made up of high vacuum rotary sealing
system, high vacuum pipeline, air inlet, air outlet, air release
valve and glass tube flange. It is used for vacuum sealing of glass
tubes in the laboratories of universities and research institutes.
Batch factory test tube sealing. Vacuum seal of quartz glass test
tube; Borate glass vacuum seal, etc. The vacuum sealing system
developed by the company is simple and fast to operate, and adopts
the unique rotating sealing flange, which can adjust the sealing
speed of the test tube at will, and can be sealed without manual
rotation of the test tube, greatly improving the sealing efficiency
of the test tube.
Product Description
DYFK-1 series quartz tube vacuum sealer/system
This series of vacuum sealing machine/system is mainly used for
sample without oxygen and water in vacuum sealed and high
temperature solid phase synthesis, the system consists of vacuum
sealing machine, hydrogen and oxygen machine, molecular pump
system, quartz tube, connector, etc, standardized custom quartz
tube and quartz column guarantee exactly match the rest of the
special design of pipe joint, so as to further enhance the sealing
of the quartz tube, achieve higher standards of vacuum tube.
Product advantages
1. High temperature welding of quartz tube wall and built-in quartz
column
2. Automatic seal and rotating, simple operation, even heating.
3. Vacuum system with side pumping system, powder is not easy to be
drawn out.
4. High vacuum tube joint connection, sealing good vacuum.
5. Compact structure, precise design, compact size and convenient
operation.
6. Hydrogen-oxygen electromechanical hydrolysis aquatic gas,
instantly producedand consumed, safe and environmental protection.
| Name | Rotary quartz tube vacuum sealing system |
| Number of workstations | 1 - 3 |
| Vacuum leakage rate | 2x10-11 Pa·m3/S |
| Rotating Speed | 0-30r/min adjustable |
| Thickness of Sealed Tube Wall | ≤ 5 mm |
| External Diameter of Sealable Tube | 5mm - 50 mm |
| Sealable test tube length | 100-1000mm |
| Vacuum Connection | KF25 vacuum baffle valve |
| Air escape valve | KF16 |
HHO oxyhydrogen generator
It is able to separate clean soft water (H2O) into hydrogen and
oxygen gases, using a small amount of electric power through a
special process, in which hydrogen is used as a fuel and oxygen is
used for combustion.
It can replace carbonaceous gases such as acetylene, gas and
liquefied gas without additional oxygen cylinders. It is safe,
efficient, environmentally friendly and energy-saving.
